| Housing | 12# Die-casting dark grey powder coated aluminum T=60–80µm Adhesion of ISO class 1 / ATM class 4B |
| Front Cover | Hard chrome-plated stainless steel SUS 316L# |
| Light Window | Tempered frosted step glass, T=8mm |
| Reflector | Optical reflector efficiency ≥ 90% |
| LED | CITIZEN COB |
| Glass Pressure Capacity | Full Area = 2526 kgs |
| Cable Gland | IP68 PG-9 PA66 |
| Gasket | Molding shaped seal |
| LED Driver | Constant Voltage Input, Constant Current Output |
| Operating Temperature | -20°C to 50°C |
| Power Cable | H07RN-F 2×1.0mm² L=0.5m (low voltage) H07RN-F 3×1.0mm² L=0.5m (high voltage) |
| Mounting Sleeve | ABS 067# |
| IK / CCT / CRI | IK07 / 3000K / CRI 80 |
